Instrumentation Tube Plug Manufacturer in India
Vintex Steel Engg. Co is a trusted Instrumentation Tube Plug Manufacturer in India with a range of precisely designed tube plugs that ensure efficient sealing and long service life. The Instrumentation Tube Plugs designed by the company are made from quality material, making them stronger and more capable of withstanding high pressure and temperature conditions. The products are designed with standard specifications.
Instrumentation Tube Plug Supplier, Exporter in India
As a trusted Instrumentation Tube Plug Supplier in India, a comprehensive range of tube plugs is provided for different projects and purposes. Being a trustworthy Instrumentation Tube Plug Supplier, it is ensured that quality is maintained and products are supplied as and when required for different projects. These tube plugs are widely used in various industries where secure sealing and protection of tubing systems is essential.
Material Specification Chart Of Instrumentation Tube Plug
| Instrumentation Tube Plug | Specifications |
| Size Range | 1/8″ to 2″ |
| Pressure Rating | Up to 6000 PSI |
| Certifications | ISO, CE, ATex, etc. |
| Stainless Steel | SS 304, SS 316, SS 316L |
| Carbon Steel | ASTM A105, ASTM A350 |
Most Commonly used Instrumentation Tube Plug Types
Stainless Steel Tube Plugs
Square Tube Plugs
Instrumentation Tube Plug
Rectangular Tube Plugs
Tube End Plugs
Boiler Tube Plugs
Compression Tube Plugs
Heat Exchanger Tube Plug
Instrumentation Tube Plug Chemical Composition
| Material Grade (Instrumentation Tube Plug) | C | Mn | Si | P ≤ | S ≤ | Cr | Ni | Mo | Cu | Other |
|---|---|---|---|---|---|---|---|---|---|---|
| Carbon Steel A105/A350 | ≤ 0.30% | 0.60–1.35% | 0.15–0.30% | 0.035% | 0.040% | ≤ 0.30% | ≤ 0.40% | ≤ 0.12% | 0.04% max | — |
| ASTM A694 CS | similar to A105 | — | — | — | — | — | — | — | — | — |
| CF8 / 304 (A351) | ≤ 0.08% | ≤ 2.0% | ≤ 1.0% | ≤ 0.045% | ≤ 0.03% | 18–21% | 8–11% | — | — | — |
| CF3 / 304L | ≤ 0.035% | ≤ 2.0% | ≤ 1.0% | ≤ 0.045% | ≤ 0.03% | 17–19% | 8–12% | — | — | — |
| CF8M / 316 | ≤ 0.08% | — | — | ≤ 0.045% | ≤ 0.03% | 18–21% | 8–11% | 2–3% | — | — |
| CF3M / 316L | ≤ 0.035% | — | — | ≤ 0.045% | ≤ 0.03% | 17–19% | 8–12% | 2–3% | — | — |
| 17-4 PH (UNS S17400) | ≤ 0.07% | ≤ 1.0% | ≤ 1.0% | ≤ 0.04% | ≤ 0.03% | 15.0–17.5% | 3–5% | — | 3–5% | Nb/Ta 0.15–0.45% |
| Alloy 20 (UNS N08020) | ≤ 0.06% | ≤ 2.0% | ≤ 1.0% | — | — | 19–21% | 32–38% | 2–3% | 3–4% | Nb ≤1%, Fe bal. |
| 904L (UNS N08904) | ≤ 0.02% | ≤ 2.0% | ≤ 1.0% | — | — | 19–23% | 23–28% | 4–5% | 1–2% | Fe bal. |
| AL-6XN (UNS N08367) | ≤ 0.03% | ≤ 2.0% | ≤ 1.0% | ≤ 0.04% | ≤ 0.03% | 20–22% | 23.5–25.5% | 6.0–7.0% | — | N 0.18–0.25% |
Instrumentation Tube Plug Mechanical Properties
| Material Grade (Instrumentation Tube Plug) | Yield Strength (min) | Tensile Strength (min) | Elongation | Hardness (HB / HRB) |
|---|---|---|---|---|
| ASTM A351 CF8 (Cast 304 SS) | 28 ksi (193 MPa) | 65 ksi (448 MPa) | 35 % | ~140 HB |
| ASTM A351 CF8M (Cast 316 SS) | 30 ksi (207 MPa) | 70 ksi (483 MPa) | 30 % | ~156–170 HB; HRB ≤ 85 |
| WCB Carbon Steel (A216) | 36 ksi (248 MPa) | 70 ksi (483 MPa) | 22 % | — |
| ASTM A217 WC6 (Chrome-Moly) | 40 ksi (276 MPa) | 70 ksi (483 MPa) | 20 % | — |
| ASTM A217 C5 (Alloy Steel) | 60 ksi (414 MPa) | 90 ksi (620 MPa) | 18 % | — |
| Cast CA6NM (Cast 415 SS) | 80 ksi (552 MPa) | 110 ksi (758 MPa) | 17 % | — |
| Cast 17-4 PH (CB7Cu-1) | 100 ksi (690 MPa) | 135 ksi (931 MPa) | 9 % | — |
| CF3M / 316L Cast SS | 30 ksi (207 MPa) | 75 ksi (517 MPa) | 30–35 % | — |
| Hastelloy C276 | 52 ksi (355 MPa) | 115 ksi (790 MPa) | 40 % | — |
| Hastelloy C22 | 45 ksi (310 MPa) | 100 ksi (690 MPa) | 45 % | — |
| Incoloy 800 / 800H | 30 ksi (205 MPa) | 75 ksi (520 MPa) | 30 % | — |
| Incoloy 825 | 32 ksi (220 MPa) | 80 ksi (550 MPa) | 30 % | — |
Instrumentation Tube Plug Uses and Application
- Nuclear Energy Sector
- Offshore & Chemical Industry
- Engineering & Aerospace Industry
- Automotive industry
- Oil & Gas Industries
- Power Generation
- Architectural Trim and Molding
- Kitchen Benches, Sinks, Equipment
- Food Processing Equipment
Instrumentation Tube Plug Export Countries
| Countries we export Instrumentation Tube Plug: | ||||
| Saudi Arabia | USA | Oman | Kuwait | |
| Bahrain | UAE | Mexico | Canada | |
| UK | South Africa | Singapore | Malaysia | |
| Sri Lanka | Australia | Brazil | Venezuela | |
| Bangladesh | Turkey | Netherlands | Qatar | |
| Iran | Nigeria | Russia | France | |
| Italy | Egypt | Germany | Hong Kong | |
| Thailand | Indonesia | Europe | Jakarta | |
| Tanzania | Algeria | Moroco | Greece | |
| Jordan | Iraq | Azerbaijan | Kazakhstan | |
